Much earlier this year (in the second week of January 2020) we all stayed in Tweed Heads for just under a week

One of my daughters was participating in Dance Nationals so we all found ourselves having a little holiday on the side

Anyway the rest of us did the holidaying in sunny climates thing. Little did we know that Covid-19 was just around the corner

The summer bushfires were still in full swing so we had some smoky haze when visiting some inland regions. This view into the Tweed Valley with the mountains in the distance has been afforded that nice layered look

Tweed Valley

Note: These photographs (especially the wider shots) look much better when larger. To see larger versions in an inline overlay slideshow gallery viewer click any of the images.

We were staying right in the heart of Tweed Heads which allowed me a couple opportunities to head out and do some “real” photography

A quickfire trip down to Snapper Rocks just after sunset allowed a few long exposures

Tweed Flow

Snapper Rocks



Today I’m testing the Vibration Reduction (VR) capabilities of the new Nikon Z 24-200mm f/4-6.3 VR lens. This is one of the first Nikon Z FX lenses to include VR in the lens. In theory the specs say the Vibration Reduction is rated for up to 5 stops

For these tests I waited till early twilight and shot with the 24-200 attached to my Nikon Z7 at 200mm handheld

Common wisdom would say that to shoot acceptably sharp images handheld with this combination would require a 1/focal length (1/200 sec) shutter speed. Probably even faster given the Z7’s 46MP high sensor resolution

The way I completed the test is that I

• shot in Manual mode
• with the aperture fixed at f/8
• I adjusted the shutter speed and ISO between sets (doubling the shutter speed and ISO each time)
• with Vibration reduction turned ON in the camera’s menu settings Note the 24-200 doesn’t have a physical VR switch on the lens like older F-Mount lenses. The function is completely controlled from the camera

On the Nikon Z50 DX camera body (which doesn’t have IBIS) the vibration reduction works alone. The lens adds 5 stops of built-in optical vibration reduction, but also works in tandem with IBIS on Nikon bodies that include IBIS like the Z6 and Z7

I shot sets at various shutter speeds – if we say that 1/200 sec is the target “normal” then I took sets of images at 1/6 sec (5 stops slower), 1/3 sec (6 stops slower) and 0.6 sec (7 stops slower)

For each set at a certain shutter speed I took 10 images handheld with good handholding technique

When reviewing these sets of ten images in post I had roughly 4-6 images which were as sharp as what you see below. The rest would be what I would call not acceptably sharp to varying degrees. Still a 50% hit rate to me is more than acceptable at these very slow handheld speeds

In this post I’ll be showing pairs of images taken at the different shutter speeds handheld. The first of the pair is the complete image frame and the second is a 1600 pixel wide 100% crop from the frame. I’ve tried to align the 100% crop across the sets so you’ll see roughly the same spot on the tree

Vibration Reduction On (5 Stops)

Vibration Reduction (5 Stops)

Note: These photographs (especially the wider shots) look much better when larger. To see larger versions in an inline overlay slideshow gallery viewer click any of the images.

Vibration Reduction On (6 Stops)

Vibration Reduction On (6 Stops)

Vibration Reduction On (7 Stops)

Vibration Reduction On (7 Stops)

Lastly here is what you get when you take the shot with VR turned off – yes a blurry mess

Vibration Reduction Off

Vibration Reduction Off

Finally here’s one I took wide open at 200mm, earlier in the day at a more sensible 1/200 sec shutter speed handheld

Having watched Ricci’s excellent youtube video comparison of the Nikon Z 24-200mm Vs Nikon 28-300mm, one thing he showed us was the crazy levels of focus breathing that existed in the older F-Mount 28-300mm lens. Especially in comparison the the new Z-Mount 24-200mm lens which appeared to have essentially none

Why does this matter do you ask… Well for one thing – it means that whilst:

• focusing on objects near infinity, the 300mm end of the 28-300 “may” give you a magnification and Field of View (FoV) of a more telephoto 300mm lens
• however when you focus on objects that are closer, that so called 300mm lens actually gives you a field of view of a much wider (less telephoto) lens (much less than 300mm and as it turns out less than 200mm even)

So there will be folks who might be wondering about the “reach” they might be giving up if they were to switch from the F-Mount Nikon 28-300mm ultrazoom lens to the new Z-Mount 24-200mm ultrazoom lens

How much less do you ask – well I figured as I now have both lenses (my new Z 24-200 just arrived :)) I’d do some test shots

So here I’ve setup a ruler standing in front of a window and I have my camera (a Nikon Z7) on a tripod

I’ve taken pairs of test shots from the exact same camera and position (tripod hasn’t moved). All I’ve done between the two shots is swapped the lens. In the first shot I’m shooting with the Nikon Z 24-200mm f/4-6.3 VR @ 200mm and in the second I have the Nikon AF-S 28-300mm f/3.5-5.6G ED VR @ 300mm attached to the Z7 using the FTZ adapter. In both cases the in camera sensor plane is exactly the same distance from the ruler

In this first pair of shots below (Nikon Z 24-200 @ 200mm on top and Nikon 28-300 @ 300mm bottom) I’ve taken the images near the Minimum Focusing Distance (MFD) of the lens (near 0.5m)

In this case you can see that the Nikon Z 24-200 @ 200mm actually has a narrower field of view than the Nikon 28-300 @ 300mm (so that 300mm lens is actually providing significantly less than 200mm of magnification here)

Nikon Z 24-200mm f/4-6.3 VR @ 200mm near MFD (~0.5m)

Nikon AF-S 28-300mm f/3.5-5.6G ED VR @ 300mm near MFD (~0.5m)

Note: These photographs (especially the wider shots) look much better when larger. To see larger versions in an inline overlay slideshow gallery viewer click any of the images.

It’s actually not till after 1.7m away that the 300mm end of the 28-300 even comes close to matching the 200mm of the 24-200

Nikon Z 24-200mm f/4-6.3 VR @ 200mm at 1.7m

Nikon AF-S 28-300mm f/3.5-5.6G ED VR @ 300mm at 1.7m

So what does this mean… well for shooting closer subjects (like < 2m away) the Z mount 24-200 actually provides greater “reach” (a narrower field of view) at 200mm than the old F-Mount 28-300mm does even at 300mm

About a year ago I purchased a new Nikon camera body (the Nikon Z7)

It was to be a replacement for my full frame Nikon D750 D-SLR and my first foray into the mirrorless camp. One year in and the conversion, along with an accumulation of excellent Nikon Z series lenses, has been an outstanding success

I’m a compulsive researcher and ADD list maker so I’d done much research on all those little settings which are available in camera. Therefore I figured I might just share the result of my detailed study and how I’ve setup my Z7 for daily use (basically all my default settings)

Also for those who are interested I’ve previously published my recommended settings for the Nikon D90, D7000, D600 and D750

Note these settings would equally apply to the Nikon Z6 and many would likely also translate to the Nikon Z50

Firstly I should say that I primarily shoot in Aperture priority mode or Manual. This is mostly because I like to be able to control my depth of field – and because I’m mostly taking shots of landscape, people, portraits or things

So on to the Z7 camera settings I use… The following lists mostly show the settings I’ve changed which are different from the Nikon Z7 Defaults…

Z7 Settings:

Turn off touch shooting on the touch screen (only Touch AF On)
Release mode: Continuous L (2fps)
Monitor Mode Button: Prioritize viewfinder (Automatic display switch -> Viewfinder only -> Monitor only -> Prioritize viewfinder)

Z7 Playback Menu:
Display options: Highlights & RGB Histogram & Overview
Image review: On (monitor only) / Off (Default On)
Rotate tall: Off

Z7 Photo Shooting Menu:
File Naming: …
Image Quality: NEF (RAW)
Image size: RAW Large
NEF (RAW) recording -> NEF (RAW) compression: On – Lossless compressed
NEF (RAW) recording -> NEF (RAW) bit depth: 14-bit
ISO sensitivity settings: ISO 64, Auto ISO: [Max: 25600, Min Shutter: Auto]
White balance -> A Natural light auto
Set Picture Control: Neutral (Default Auto)
Long exposure NR: Off
High ISO NR: Low? (Default: Norm) – JPEG only
Vignette control: Off (Default: Norm) – tags RAW EXIF
Auto bracketing: AE bracketing (Default AE & Flash bracketing)

Z7 Movie Shooting Menu:
File Naming: …
Frame size/frame rate: 2160p25 (4K 25fps)
Movie quality: High
Movie file type: MOV
ISO sensitivity settings: ISO sensitivity (mode M): 64 (Default 100)
Set Picture Control: Neutral (Flat?) (Default Same as photo settings)
High ISO NR: Normal (Default)
AF-area mode: Auto-area AF (Default Single-point AF)

Z7 Custom Settings Menu:
a Auto Focus:
a2 AF-S priority selection: Focus
a9 Focus point wrap-around: Wrap (Default No Wrap)
a11 Low-light AF: On (Default Off)
a12 Built-in AF-assist illuminator: Off (Default On)
c Timers/AE lock:
c3 Power off delay: Playback: 10s/20s, Menus: 1m, Image review: 2s, Standby timer: 30s
d Shooting/display:
d1 CL mode shooting speed: 2 (Default 3)
d5 Shutter type: Auto
d9 Framing grid display: On
d10: Peaking Highlights: Peaking Level: 1; Peaking highlight color: Yellow
e Bracketing/flash:
f Controls:
f1 Customize i menu: See Below
f2 Custom control assignment: See Below
f3 OK button: Zoom 100% (Default RESET center focus point)
g Movie:
g1 Customize i menu: See Below
g2 Custom control assignment: See Below
g3 OK button: Zoom 100% (Default RESET center focus point)

i Menu for Photo mode:

Auto bracketing	Shutter type	Split-screen display zoom	Wi-Fi connection	Silent photography	AF-area mode
White Balance	Peaking highlights	Metering	Apply settings to live view	Vibration reduction	Focus mode

Button customization in stills mode:
Fn1: Press -> MY MENU (Default: White Balance)
Fn2: Focus mode/AF-area mode (Default: Focus mode/AF-area mode)
AF-On: (Default: AF-On)
Sub-selector: Focus point selection
Sub-selector center: Select center focus point (RESET) (Default AE/AF lock)
Movie [Rec] button: Auto bracketing

i Menu for Video mode:

Highlight Display	Frame size and rate/image quality	Microphone sensitivity	Wi-Fi connection	Electronic VR	AF-area mode
White Balance	Peaking highlights	Wind noise reduction?	Headphone volume	Vibration reduction	Focus mode

Button customization in video mode:
Fn1: Default: White Balance
Fn2: Focus mode/AF-area mode? (Default: Focus mode/AF-area mode)
AF-On: AE/AF Lock? (Default: AF-On)
Sub-selector center: Select center focus point (RESET) (Default AE Lock)

Z7 Setup Menu:
Time zone and date: …
Monitor brightness: -2 (Default 0)
Clean image sensor: Clean at shutdown
Copyright Information: …
Slot empty release lock: Lock (I want the camera to prevent me from taking a picture if a memory card is not installed)

Z7 Setup MyMenu:
Setup menu: Airplane mode
Setup menu: Format memory card
Setup menu: Non-CPU lens data
Setup menu: Monitor brightness
Setup menu: Battery info
Shooting menu: Choose image area
Shooting menu: Focus shift shooting
Custom Settings Menu: d4 Exposure delay mode (great for tripod use)
Custom Settings Menu: a5 Focus points used
Custom Settings Menu: a4 Auto-area AF Face Detection
Setup menu: Time zone and date

On top of this I also use the three User settings mode dial slots (U1, U2 & U3) to store extra customised shooting settings for quick access (e.g. one tailored for tripod style landscape shooting, one for tripod style long exposure/night photography and one for action photography). These U1, U2 and U3 slots start with the above general settings and have the following additional starting point customisations.

U3 – Landscape: Aperture Priority & f/8, ISO 64, Auto ISO Off, Single-Point AF (centre point selected) (Pinpoint AF?), Vibration reduction: Off, a4 Auto-area AF Face Detection: Off, a11 Low-light AF: On, c3 Power off delay: Playback: 20s, Menus: 1m, Image review: 10s, Standby timer: 1m, d5 Shutter type: Auto, d10 Peaking highlights: On/2

U2 – Long Exposure/Night: Manual & f/8, ISO 64, Auto ISO Off, Single-Point AF (centre point selected) (Pinpoint AF?), Vibration reduction: Off, a4 Auto-area AF Face Detection: Off, a11 Low-light AF: On, c3 Power off delay: Playback: 20s, Menus: 1m, Image review: 10s, Standby timer: 1m, d5 Shutter type: Auto, d10 Peaking highlights: On/2

U1 – Action: Aperture Priority & f/2.8, Auto ISO On [Min Shutter: Auto*2], Continuous-Servo AF (AF-C), Dynamic/Auto Area AF, RAW 12 bit compressed (increases buffer depth), Metering Center-weighted?, Vibration reduction: SPT (Sport), a1: AF-C priority selection: Release, a3 Focus tracking with lock-on: 4, a5 Focus points used: 1/2 Every other point, a6 Store points by orientation: On, a7 AF activation: AF ON only? (back button focus), d1 CL mode shooting speed: 5fps, d8 Apply settings to live view: Off, d9 Framing grid display: Off?
